Norco Fluid FS 1

2021 Norco Fluid Full-Suspension (FS) 1

2021 Norco Fluid FS 1

Frameset

• Size: Large
• Wheel size: 29"
• Frame: 6061 Alloy Trail, 120mm Travel
• Fork: RockShox Pike Select, 130mm Travel, 51mm Offset
• Rear shock: RockShox Deluxe Select, 190x45mm
• Mass: 16.4 kg

Drivetrain

• Rear shifter: Shimano SLX SL-M7100-IR I-Spec EV
• Rear derailleur: Shimano XT RD-M8100
• Crankset: Shimano FC-M610, 30T, 175mm
• Bottom bracket: Shimano Cartridge Bearing, BSA Threaded
• Cassette: Shimano SLX, 10-51, 12 Speed
• Chain: Shimano Deore
• Pedals: VP Nylon Flat (OEM) / Replaced with alloy Azur Stout

Brakes

• Front brake: Shimano BR-MT420, 4 Piston, Organic Pads
• Front brake rotor: Shimano SMRT54 180mm
• Rear brake: Shimano BR-MT420, 4 Piston, Organic Pads
• Rear brake rotor: Shimano SMRT54 180mm
• Brake levers: Shimano BR-M420

Components

• Handlebar: TranzX 6061 Butted Alloy, 780mm, 20mm Rise
• Stem: 6061 Alloy, 50mm Length, 35mm Clamp
• Seatpost: X-Fusion Manic Dropper, 170mm
• Dropper lever: Norco Dropper Lever
• Headset: Sealed Bearing, Tapered
• Saddle: Fizik Taiga
• Grips: VP Lock-On

Wheels

• Front hub: Shimano HB-MT400-B, 15x110mm Boost, Center Lock
• Rear hub: Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
• Rims: Stan's Flow D 32H
• Tyres: Maxxis Dissector 29x2.40 Wide Trail (WT), 3C MaxxTerra, EXO protection, Tubeless Ready (TR)
• Spokes/Nipples: Stainless, Black

Geometry

Large Frame Geometry
HTA	Head Tube Angle	66.5°
OS	Fork Offset	51 mm
ST	Seat Tube Length	450 mm
STA	Effective Seat Tube Angle	76.0°
RC	Rear Centre Length	429 mm
BB	Bottom Bracket Drop	36 mm
BBH	Bottom Bracket Height	342 mm
HTT	Horizontal Top Tube	623 mm
WB	Wheelbase	1204 mm
SOH	Standover	694 mm
HT	Head Tube Length	110 mm
Reach		470 mm
Stack		612 mm
Trail		109 mm
